Canyon Neuron:ON AL 9
Model: Neuron:ON AL 9
Model year: 2025
Category: Fully
Frame material: Aluminium
Weight: 24.95 kg
Wheel size: 29"/622mm
Verdict on the Neuron:ON AL 9 test
The Canyon Neuron:On AL 9 is a comfort-orientated all-rounder that masters both everyday use and trail tours with ease. Its modern equipment, reasonable weight and comfortable riding position make it an attractive choice for riders who value versatility and value for money - even if it doesn't offer the greatest reserves in extreme terrain. - Florentin Vesenbeckh, Deputy Editor-in-Chief BIKE Magazine
Geometry - measurements overview
A
H
I
C
P
O
D
B
N
M
G
E
F
L
| A - Handlebar width | 780 mm |
| B - Seat tube length | 430 mm |
| C - Federweg Rahmen | 140 mm |
| D - Standover height | 785 mm |
| E - Chainstay length | 457 mm |
| F - Bottom bracket height | 333 mm |
| G - Wheelbase | 1275 mm |
| H - Stem length | 45 mm |
| I - Head tube length | 143 mm |
| L - BB offset | -38 mm |
| M - Stack | 658 mm |
| N - Reach | 478 mm |
| O - Seat angle | 77 ° |
| P - Head angle | 65.1 ° |
| Top tube length | 630 mm |
Tests & Reviews
Equipment
| Rear brakes | SRAM DB8 |
| Front brakes | SRAM DB8 |
| Front brake disc | 200 |
| Rear brake disc | 200 |
| Front brake lever | SRAM DB8 |
| Rear brake lever | SRAM DB8 |
| Drivetrain | SRAM Eagle S1000 Transmission AXS |
| Shift levers | SRAM AXS Pod Controller |
| Drivetrain type | Derailleur |
| Number of gears | 12 |
| Fork | Rock Shox Lyrik |
| Rear shock | Rock Shox DeLuxe Select RL |
| Bottom bracket | Bosch |
| Crankset | FSA CK-745 Alloy |
| Sprocket | SRAM XS 1275 |
| Drive type | Kette |
| Headset | Acros Block Lock |
| Handlebar | Canyon On Alloy |
| Grips | Canyon Schraubgriffe |
| Stem | Canyon On Stem |
| Saddle | Fizik Alpaka |
| Seatpost | Canyon Dropper Post |
| Seat clamp | Clamp |
| Wheelset | DT-Swiss H 1900 Spline Hybrid |
| Wheel size | 29"/622mm |
| Front tire | Schwalbe Magic Mary Evo TLE SuperTrail Addix Soft 29 x 2,40 |
| Rear tire | Schwalbe Hans Dampf Evo TLE SuperTrail Addix SpeedGrip 29 x 2,35 |
| Motor manufacturer / model | Bosch Performance CX |
| Motor type | up to 25 km/h |
| Motor position | Mid-drive motor |
| Display | Bosch Kiox 300 |
| Control unit | Bosch Mini Remote Flat BRC 3300 |
| Battery | Bosch Power Tube 800 |
| Battery capacity (Wh) | 800 |
| Charger | Bosch 4Ah |
